Minew I6 3.3mm thinnest slim sticker nrf51822/nRF52832 bluetooth eddystone beacon

FOB Reference Price:Get Latest Price
$1.00 - $6.90 / Pieces | 3 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Model Number:
i6
Brand Name:
Minew
Place of Origin:
Guangdong, China
Name:
bluetooth eddystone beacon
Chipset:
Nordic NRF51822
Features:
iBeacon Protocol
Product Size:
32*23*3.3
Radio Fequency:
2.4GHz
Transmission Range:
50 m
Power Comsuption:
average 35uA
Battery:
CR2016
Battery Life Span:
6 months
OEM/ODM:
Yes
Supply Ability
Supply Ability:
50000 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
Packaging Details:
Industrial Package Box: 30.5*11*7.5 cm, 100pcs per inside package box.
Master Package Carton:32 x 23.5 x 40 cm, 1000 pcs per outside per carton.
Port
Shenzhen
Product Description
Minew I6 3.3mm thinnest card shape slim sticker nrf51822/nRF52832 bluetooth ibeacon eddystone beacon OEM/ODM/OBM

i6 is a BLE (Bluetooth Low Energy / version smart 4.0 / 2.4GHz) Beacon with smallest size. Cover the range to 50m and reduce the power comsuption to 35uA average only
As it is an active tag, it is battery powered and been developed to work with iOS 7.0 and Android 4.3+System competible.
It will always broadcast the iBeacon frames like UUID, Major, Minor, you could set those parameters as well as transmission power, broadcast internal ... via our comfiguration APP " BeaconSET ".

Technical Datas:
    Working frequency: ISM frequency 2.400~2.483GHz
    Broadcast range: 100m max
    Battery capacity: 6 months
    SDK: available
    Average power consuption: 35uA

 Advantages:
    Square shape, 3.3mm thin
    Standard iBeacon protocol, UUID, Major, Minor
    Accurate locating.
    Use low power consumption chipset nRF51822 with Cortex -M4F CPU
    Excellent security mechanism
    Support the customized service such as firmware, logo and other

Technical Spec
Item
Value
Remarks
Chipset
nRF51822
128k Flash 16K RAM
BLE
4.0
Low power consuption
System
ios7.0/ Android 4.3 above

Protocal
standard iBeacon
UUID Major, Minor
Battery
CR2016

Transmission Range
100m
Max
Size
32*23*3.3mm
Ultra-thin
Accessories
Adhesive
3M
Antenna
50 ohm
on PCB
Application


Ultra thin Bluetooth 4.0/ble 5.0 thinnest and smallest iBeacon tag Support IOS And Google Eddystone


Accurate Indoor Location
    --i6 is able to detect distance even calculate its position within the range.


Asset Tracking
    --i6 eddystone/ibeacon broadcasts and transmits 2.4GHz radia signals at the regular and adjustable intervals.


Logistics Management


Commercial Advertising

    --For traditional offline retailers, engage your customers and visitors through context based and personalized advertising.- Optimize shopping experience.



Application 2

      You could also use this product together with our IoT gateway G1. G1 is desined as a cloud service and it coud collect the data signal broadcasted from the i6 beacon and then store the data for deployers' later use.

Packing & Delivery

               For samples: we would send samples via DHL Express within about 2 days after payment, then you would receive them in about 4 to 5 days.

          For orders: bulk orders usually take about 2 to 3 weeks after payment received

Details
Gift Box
Industrial Box
Master Carton
Quantities (i6)
10 pcs/ box
100 pcs/box
1000 pcs/box
Size
17.5*11.2cm
30.5*11*7.5cm
32*23.5*40cm
Gross Weight
60g
530g
6.1kg
You May also Like

        E7 rotatable case beacon

         i9 small round beacon



            G1 gateway device

Certifications
Our Company

       Minew specialized in IoT (Internet of Things) field, focus on high quality beacon device development, from the design, manufacture to sale. We established since 2007 and is the leading IoT related manufacture now.

      Via providing smart devices and IoT solutions, we serve to optimize customers' lives, works and businesses, improving efficiency and convenience.
     We have/certificated:
        IOS9001:2008 Quality Management System
        Professional R&D team, sales team and effective production line
        CE, FCC, RoHs, ANATEL, Japan Radio Frequency Permit

Exhibitions

     Every year, we would attend exhibitions both at home and abroad. Such as the CES Vegas, Cebit Hanover and so on, hope to have a have meet with you then.


F&A:



    Q1: Do you provide the technical support to the developers?

      A: SURE. The following technical data and documents will be provided.
         1. SDK     2. API   3. Demo APP     4. Configuration APP   5. Instructions

    Q2: Can we brand your product with our company LOGO?
      A: Yes, We offer the OEM/ODM service.

     Q3: How can we get the samples to test?
       A: You can confirm the order on Alibaba or contact us to pay it via Paypal , samples can supply from stock. you can receive the samples within 3-4 days after you pay it.

      Q4: Do you have any certificats?
        A: Yes, we have CE, RoHs, and FCC for all of our products.

      Q5: What's the warranty of the product?
        A: we supply 1 year warranty from the shipping date, any damage caused during the production would be replace by a new one.
