New Bluetooth 5.1 beacon AoD supported for location service market

FOB Reference Price:Get Latest Price
$6.00 - $12.00 / Pieces | 3 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Model Number:
i3
Brand Name:
Minew
Place of Origin:
Guangdong, China
Product name:
i3 Robust Beacon
Chipset:
Nordic nRF52
Battery:
Powered by 2pcs AA batteries, alkaline
Advertising distance:
200 meters (Max)
Transmission power range:
-30dBm to +4dBm
Broadcastng interval:
500ms
Case color:
Black & White
Size:
72*45*22mm
Application:
High precision location
Protocol:
Bluetooth 5.1
Supply Ability
Supply Ability:
50000 Piece/Pieces per Day
Packaging & Delivery
Packaging Details
i3 robust beacon package:
2pcs/pack, 8pcs/box, and 80pcs/carton.
Port
Shenzhen
Product Description

The robust MiniBeacon i3 is an enterprise-level iBeacon with ARM core chipset nRF52  and leverage BLE 5.1 Technology; it has a strong & waterproof case, accurate hardware and robust firmware. It is designed for the commercial advertising and indoor location-based service. Minew Beacons broadcast 2.4GHz radio signals at regular and adjustable intervals. MiniBeacon can be heard and interpreted by iOS and Android BLE-enabled devices that are equipped with many mobile apps.

Feature of i3 Robust Beacon:

-Programmed MiniBeacon standard firmware

-Powered by 2pcs AA batteries, alkaline

-Omni-directional PCB antenna

-The max. 200 meters advertising distance

-waterproof IP65

-Ultra-low power consumption nRF52 series chipset with ARM core

Sample application of Beacon:

1.Museum : A visitor at a museum automatically receives information about an exhibit when standing in front of it.


2. Coupons: Customers at a retail establishment receive coupons for promotional items as they enter the store.


3.In retail: In retail, a department store uses monitoring to analyze in-store behavior of their customers, assess the effectiveness of marketing programs and promotions, and learn about their staff's utilization.


4.At venues with multiple floors and buildings, mobile apps are provided for visitors to install on their phones or tablets, enabling them to find their current position and receive turn-by-turn guidance to reach their destinations.


5.INDOORS: A hospital can provide its staff with wearables to track their whereabouts.

Specification:

Compatiblity
Supported iOS+ and Android 4.3+system,  Apple iBeacon TM standard, and all bluetooth 4.0 ( BLE) devices;
Configurable Parameters
UUID, Major, Minor, Device name, Password etc.  Special Configuration App;
Transmission Power Levels
8 adjustable levels, range from 0 to 7, transmission power range; -30dBm to +4dBm;
Long Battery lifetime and Battery Level
5 years, with the default setting, LED will be flashing when battery  low, Easy to get the real-time battery level notification.
Security
8 characters password ( Lock/Unlock parameters), Broadcast the encrypted data if needed.
Connection Mode
Advertising mode, non-connectable; Configuration mode, Connectable.
Long range
The max. Range 200 meters in the open space; The range depends on the physical environment;

Configurable Parameters:  UUID, Major, Minor, Device Name, Password etc.


Battery lifetime and Battery level: 5 years with the default setting, easy to get the real-time battery level notification.


Long Range: Range 200m (max) in the open space. The range depends on the physical environment.


Mounting: 3M branded adhesive for direct mounting to wall, bracket for mounting on non-metal wall by two screw holds.


Connection Mode: Advertising mode, non-connectable; Configuration mode, connectable.

Item
Value
Remarks
Case Color
Black, white
Other colors can be customized
Battery Model
2*AA( LR6)
2pcs Alkaline battery, 2500mAh, 3.0V
Operation Voltage
1.8-3.6V
DC  iBeacon
Transmission Range
200 meters
Maximum Eddystone
Antenna
50ohm
On board/ PCB Antenna
Accessories
Double adhesive
1pc, high-strength, 3M brand;
Screws
2pcs screw and 2pcs plastic holders
Net weight
50g
Without battery and package box
Size
72*45*22mm
Null
Related Products

E9 D-ear Beacon

E2 Max Beacon


E5 Beacon

Our Company

Founded in 2007,Minew has been engaged in IoT (Internet of Things) field for years and is keeping updated to the market demand all along.We are an ISO9001:2008 certified manufacturer focusing on RF / Wireless products such as 2.4GHz BLE 4.0 related products.We focus on designing and manufacturing many

different high quality and low cost iBeacons hardware , offering one-stop services include:

1. Schematic design;
2. Mold design;
3. PCB layout;
4. Firmware design;
5. Production and assembling.
Warmly welcome the OEM and ODM projects.

Certifications

CES show in Las Vegas Jan. 2017

Packing & Delivery

Packing


Delivery

1. According to our customers requirements, we are willing to handle shipment for our customers, and the shipment fee is needed in this case.Fast Express like DHL,UPS, TNT, FedEx are all available here.


2. If our customers have their own Express account, freight forwarder in China,we are happy to contact their Express people or freight forwarder to pick up products from our factory.

FAQ

Do you provide the technical support to the developers?
Re: SURE. The following technical data and documents will be provided to developers.
1. SDK 2. Firmwork 3. Demo APP 4. Configuration APP 5. Instructions


Can I change the password?
Re: Yes, you can use configuration APP to change password by yourself.


Do you have SDK or the source code?
Re: Yes, we will provide you after sample was arrived.

Does MiniBeacon comply with iBeacon standard?
Re: Yes,MiniBeacon has been licensed by ibeacon stamdard program with contact No.iBC-14-00582.
